Image Part Key Part Number Description Unit Price Desired Quantity
CF13DD/827
13 Watt Florescent Bulb
$9.57
1 S44388000
Hanger Bar
$3.15
3 S99270981
Receptacle - White
$2.11
4 S99270489
Receptacle - (Red)
$4.16
4 S99270982
Receptacle - Black
$2.11
5 88568000
Heater Kit - Version 1 Plastic Housing ( Includes,7,8,9,10 Ver#1)
$94.54
5 S97017648
Heater Assembly Complete (Metal Housing 2010 And Newer ver#2 )
$67.48
6A S97005058
Bolt (New Current Metal housing 2010 )
$3.22
6B S99020290
Blower Wheel (New Current Metal housing 2010 )
$11.27
6E S99270107
Heater Hooks (New Current Metal housing 2010 )
$1.64
6G S98010295
Heater Scroll Cover(Version #2)
$6.70
6H S97017070
Heater Scroll Housing (Version #2)
$12.87
11 86693000
Vent Motor Assy - Motor/Bladeto Fit Into Your Plastic Housing, Prior To 2005 (Includes 10A,10B
$48.35
12 S89852000
Grille & Lens Plastic 16 1/4" X 9 3/4" X 1 3/4"
$31.59
13 S53740000
Lens - (5 1/4" X 9 3/4")
$11.84
6J S99080593
Heater Motor - CCW, For Current Version Fits Into Metal Housing #6 (2008 & Newer)
$34.38
6K S98004514
Heater Element Current After 2008 (Version #2)
$9.29
6 S61579000
Scroll Plastic Heater(Version #1)
$6.64
7 S88569000
Heat Motor Only - For Version 1 Fits Into The Plastic Housing
$45.67
8 S66583000
Blower Wheel - (Heat), Cw, 3 3/4" X 2"(Version #1)
$19.01
9 S0969B000
Heater Element - (Includes Thermal Protector Ver#1)
$25.99
10 S97017646
Vent Assembly Complete(New Metal Flat Bracket, Motor,Bladever#2,)
$36.49
11A S82403000
Blower Wheel - White Plastic, 5"X 1 1/4" (Version #1)
$4.52
11B S99080592
Motor - Vent For Current Version After 2008(Version #2)
$33.19
11A S65462000
Compression Clip To Hold Blower Wheel On Motor Shaft
$1.48
11C S97017080
Motor Mounting Plate
$10.57
11D S99260428
Motor Nut
$0.82
14 S101183000
Duct Adapter
$8.01
16 S89876000
Reflector
$33.54
17 S89878000
Cord Set
$7.00
